- Module No：G104X1-L03
- Brand：INNOLUX
- Size：10.4
- Resolution：1024X768
- Brightness：350 cd/m2
- Viewing angle：88/88/88/88
- Interface：LVDS
- CR：1000:1
- Operating Temp.: -20 ~ 70 °C
- Parameters
| Manufacturer | Innolux |
| Model Name | G104X1-L03 |
| Screen Size | 10.4” |
| Pixel Number | 1024X768 |
| Active Area(mm) | 210.4 (H) x 157.8 (V)(mm) |
| Outline(mm） | 238.6(H)x 175.8(V) x 7.5(D)(mm) |
| Treatment | AG |
| Luminance | 350cd/m2 |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 88/88/88/88 |
| Response | 25ms |
| Work Mode | Super MVA, Transmissive mode / Normally black |
| Color Depth | 16.7m |
| Backlight | LED ,30k Hours |
| Net Weight | 280g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS |
| Voltage Supply | 3.3V |
| Temperature | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| Package | CMI original package; 18 pcs/carton; Carton size: 465x362x314 mm; Gross weight: 8.3 Kgs. |
Innolux 10.4 inch industrial IPS LCD screen G104X1-L03 with resolution 1024x768 and brightness 350nits.
Robust MVA mode, work temperature -20 ~ 70 °C .
Touchscreen and HDMI driver optional dor different boards.
