Friendly Elec SOM-4418 + Edge-RT300 Development Board

Regular price $54.75
Regular price Sale price $54.75
Sale Sold out
Delivery Guarantee

Delivery Guarantee

Technical Support

Technical Support

Friendly Elec SOM-4418 + Edge-RT300 Development Board



  • The Edge-RT300 is designed and developed by FriendlyELEC for professional and enterprise users. It is based on SOM-4418.
  • The Edge-RT300 has rich interconnection interfaces, including dual RJ45 ethernet ports, Wi-Fi, BT, 4G, RS-485 and M-BUS master, which makes it suitable for IoT applications.



Introduction


Overview

2 Hardware Spec

  • CPU Board: SOM-4418
    • SoC:Samsung S5P4418 Quad Core Cortex-A9 with dynamic frequency scaling up to 1.4G Hz
    • System Memory:1GB 32bit DDR3 RAM
    • eMMC:8GB
  • Connectivity:
    • One 10/100/1000Mbps Ethernet Port (Native MAC, PHY is RTL8211E) with unique MAC, support WOL(Wake On Lan)
    • One 10/1000Mbps Ethernet Port (USB to LAN, RTL852B)
    • One MiniPCIe Socket & MicroSIM Card Slot for 4G module
    • One 802.11b/g/n Wi-Fi & Bluetooth 4.0 (AP6212)
    • One TTL to RS-485 converter
    • One TTL to wired M-BUS Master converter
  • Video Input: MIPI-CSI
  • Video Output: LVDS
  • Audio: 2-Chanel headphone output, one Microphone input
  • USB: 1 x USB 2.0 Host(Via USB Hub), 1 x USB 2.0 OTG
  • LED: 1 x power LED , 2 x User LED
  • Key: 1 x User Key, PowerKey, Reset key, SD/MMC Boot Select key
  • Other Resource: 1 x MicroSD, RTC battery input, 2-pin ZH connector for 5V cooling fan
  • Power: DC 12V/2A
  • PCB: Four Layer, 96 mm x 90 mm x 1.6mm
  • Working Temperature: -40℃ to 70℃



More information for SOM-4418 + Edge-RT300, please contact us
