NEO Basic Starter Kit

 Introduction

  • The NanoPi NEO2 is a newly released super tiny ARM board by FriendlyElec. It uses Allwinner’s 64-bit H5 quad-core SoC (ARM Cortex-A53). It has internal hexa-core Mail450 GPU, 512M DDR3 RAM. A UbuntuCore and Armbian image files are ready for it.
  • The NanoPi NEO2 inherits NEO's form factor and has compatible interfaces and ports with NEO. In addition in such a small dimension it has Gbps Ethernet and one USB host port. These features make it especially suitable for applications that require high data throughput , speedy data transmission and high performance. Hobbyists and makers will just love it.


2
 Hardware Spec

  • CPU: Allwinner H5, Quad-core 64-bit high-performance Cortex A53
  • DDR3 RAM: 512MB
  • Connectivity: 10/100/1000M Ethernet, RTL8211E-VB-CG chip
  • USB Host: USB Type A x 1 and USB pin header x 2
  • MicroSD Slot: MicroSD x 1 for system boot and storage
  • LED: Power LED x 1, System LED x 1
  • GPIO1: 2.54mm pitch 24 pin-header, compatible with Raspberry Pi's GPIO pin1 - pin 24. It includes UART, SPI, I2C, IO etc
  • GPIO2: 2.54mm pitch 12 pin-header. It includes USB, IR receiver, I2S, IO etc
  • Serial Debug Port: 2.54mm pitch 4pin-header
  • Audio In/Out: 2.54mm pitch 4 pin-header
  • MicroUSB: Power input(5V/2A) and OTG
  • PCB Dimension: 40 x 40mm
  • Working Temperature: -20℃ to 70℃
  • Weight: 13g(WITHOUT Pin-headers)
  • OS/Software: u-boot,Ubuntu Core

More information about NEO Basic Starter Kit, Please contact us.
