Banana Pi BPI-R3 Mini Router Board
Introduction
Banana Pi BPI-R3 Mini Router board with MediaTek MT7986A(Filogic 830) quad core ARM A53 chipdesign ,2G DDR RAM ,8G eMMC flash onboard,It is a very high performance open source routerdevelopment board,support Wi-Fi6 2.4G/5G with MT7976C, support 2x 2.5GbE ethernet port.
Banana Pi BPI-R3 Mini Router Board main key feature has below;
Key Features
- MediaTek MT7986A(Filogic 830) Quad core ARM Cortex A53
- Wifi 6 2.4G/5G（MT7976C）
- 2G DDR RAM
- 8G eMMC flash
- 128MB Nand flash
- 2x 2.5GbE network port
- 1x M.2 Key B USB interface
- 1x M.2 KEY M PCIe interface
Hardware Spec
|
CPU |
MediaTek MT7986A(Filogic 830) Quad-core ARM Cortex-A53 |
|
SDRAM |
2 GB DDR4 |
|
On board Storage |
128MB SPI NandFlash，8GB eMMC |
|
On board Network |
2x 2.5GbE Ethernet |
|
Wifi |
Wifi6 2x2 2.4G + 3x3 5G(MT7976C) |
|
M.2 Key B |
1x M.2 Key B interface |
|
M.2 Key M |
1x M.2 KEY-M PCIe inerface |
|
USB |
1x USB 2.0 |
|
Buttons |
Reset button, boot switch |
|
5x Leds |
Power ,System, Wifi 2G ,Wifi 5G ,4G Lte ,SSD |
|
DC Power |
20W/12V,USB TypeC PD |
|
Sizes |
65x65mm |
|
Weight |
100g |
For more information about Banana Pi BPI-R3 Mini Router Board, please contact us.
