ZHICHUN

Zhichun Z Series 15,6 inch Capacitive Touch Industrial Display

Regular price $215.06
Regular price Sale price $215.06
Sale Sold out
Shipping calculated at checkout.
Delivery Guarantee

Delivery Guarantee

Technical Support

Technical Support

Zhichun Z Series 15,6 inch Capacitive Touch Industrial Display



PRODUCT INTRODUCTION OF Zhichun Z Series 15,6 inch Capacitive Touch Industrial Display

Style Z touch monitor is a model of industrial fanless wall-mount designed based on a capacitive touch screen monitor. It has tough characteristics such as dustproof, waterproof, and oil resistant. The display screen is available in 7, 8, 10.1, 10.4, 12.1, 13.3, 15, 15.6, 17, 19 and 21.5 inches.

Specification:

Parameter

Interface Parameter

USB

1 * USB-B

DC

1 * DC

HDMI

1 * HDMI

VGA

1 * VGA

Audio

Line-out

Touch Screen

Type

PCAP Touch

Respond Time

≤5ms

Luminousness

85±5%

Surface Hardness

6H

Click Lifetime

50 millions times

Anti Static Pressure

5kg/cm2

Communication Interface

USB interface

Display Screen

Type

15,6 inches

Interface

LVDS

Backlight

LED

Backlight MTBF

50000h

Resolution

1366x768

Brightness

300cd

Dynamic Contrast

1000:1

Viewing Angle

R/L:65(Typ.), U/D:65(Typ)

Environmental Parameters

Operating Temperature

           -10-+60

Storage Temperature

            -20-+70

Relative Humidity

              20%-90%

General Parameters

Outline Dimension

401.54mm×250.83mm×49mm(L*W*H)

Display Dimension

343.54mm×192.83mm(L*W)

Hole Size

389.54mm×238.83mm(L*W)

Shell Material

Front panel aluminum alloy + metal plate backcover

Installation Type

Embedded,Wall-Mounted,Desktop,VESA



Accessories:                                                Optional Accessories

Product Name

Specification



Product Name

Specification

Mounting strip

2 PCS



Wall-Mounted Plate

Wall-mounted using optional

Adapter

12V/5A



Desktop Stand

Desktop installation optional

Power Cable

1.5M







Touch Pen

1 PCS







Manual/Warranty Card

Each 1 PCS







Wires

1 * 1.5M VGA cable

1 * 1.5M USB cable








For more information about Zhichun Z Series 15,6 inch Capacitive Touch Industrial Display, please contact us
