- Rockchip RK3568 Quad-core ARM Cortex-A55 CPU
- Mali-G52 1-Core-2EE
- 2G LPDDR4 SDRAM (option 4G)
- Mini PCIE interface and M.2 key-e interface
- support 1 SATA interface
- MicroSD slot supports up to 256GB expansion
- 16G eMMC flash (option 16/32/64G)
- 2 MIPI display interface support
- 1 CSI camera interface
- 5 port 10/100/1000 Mb Ethernet port
- (2) USB 3.0 and (1) USB 2.0 otg port
Banana Pi BPI-R2 Pro is the next generation smart router developement board from Banana Pi in 2021. It is powered by Rockchip RK 3568 processor.Onboard 2GB LPDDR4 memory and 16GB eMMC storage, and supports 2 USB 3.0 interface, 5 gigabit network port. M.2 key-E and mini PCIe interface, 2 mipi DSI interface(one can change to LVDS by software), 1 CSI camera interface,1 HDMI output,support Android，Linux,OpenWRT system
BPI-R2 Pro same size as Banana Pi BPI-R2 , and interface is also same .so can use BPI-R2 case.
Hardware interface:
Hardware spec:
| Banana Pi R2 Pro | |
|---|---|
| CPU | Rockchip RK3568 Quad-core ARM Cortex-A55 CPU 2GHz |
| GPU | Mali-G52 1-Core-2EE OpenGL ES3.2 Vu1kn 1.1 OpenCL 2.0 |
| Memory | 2G DDR3 SDRAM (option 4G) |
| Storage | Onboard 16GB eMMC Flash, Micro SD-Card slot, SATA 2.0 Port,SPI flash |
| Network | 5 x 10/100/1000 Mbit/s Ethernet |
| Display(s) | 1 HDMI port, 2 DSI interface(1 DSI can change to LVDS by software) |
| Camera | 1 CSI camera interfact |
| Video decoder(s) | H.265 HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096x2304@60fps,H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096x2304@60fps |
| Video encoder(s) | H.264/AVC BP/MP/HP@level4.2，up to 1920x1080@100fps, H.265/HEVC MP@level4.1, up to 1920x1080@100fps (4096x4096@10fps with TILE) |
| Audio Output(s) | HDMI & I2S & Speaker & Headphone |
| USB port | USB 3.0 PORT (x2), micro USB OTG (x1) |
| mini PCIE | 1 mini pcie interface & 1 M.2 key-e interface |
| Remote | IR Receiver (x1) |
| GPIO | 40 Pin Header : GPIO (x28) and Power (+5V, +3.3V and GND). Some of I/O Pin can be used for specific functions as UART, I2C, SPI or PWM |
| Switches | Reset button, Power button, U-boot button |
| LED | Power Status and 8P8C |
| Power Source | 12 volt @2A via DC Power and/or Micro USB (OTG) |
| Size & Weight | 148 mm × 100.5mm 100g |
| OS | OpenWRT, Linux and others OS |
